Unit functions
Rear view
8
7
1 Carrying handle and suction tube storage
during transport
2 Mains cable retractor
3 Unit housing, upper section
4 Bracket, upholstery tool (optional)
Page 4 / 29
5 Unit housing, lower section
6 Bracket, upholstery tool (optional)
7 Mains cable
8 Bracket, floor tool with suction tube
New Unit Information 05.2007
