Front Panel Lock/Unlock

The Front Panel Lock/Unlock feature allows you to lock the menu,
preventing unauthorized users from modifying printer settings. The front
panel is locked and unlocked with a user-defined four-digit password.
When the front panel is locked, users can scroll through the menus, but
cannot make any changes. The only available features are PRINT/PAUSE,
FORM FEED/ADVANCE, Printer Settings, and Front Panel Unlock.
An "X" character will appear on the Ready and Pause displays to indicate
the front panel is locked.
Ready
Pause
To lock the front panel:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the System menu is displayed.
Then press the SELECT key.
Pause: System
3 Press the NEXT or PREVIOUS key until the Front Panel Lock menu is
displayed.
QLS-4100 Xe
Press SELECT
Front Panel Lock
0000
X
X
