Evaluating Print Quality

1 Press the PRINT / PAUSE key to put the printer into the pause mode.
2 Press the NEXT or PREVIOUS key until the Cal & Setup menu is
displayed.
Pause: Cal & Setup
3 Press SELECT. Then press the NEXT or PREVIOUS key until the Test
Print menu is displayed.
4 Press the + or - key to scroll through the test patterns and select Test
Pattern: x in. at a width that is appropriate for the width of your media.
Print widths for the Test Pattern are 1, 2, 3, 4, or 5 inches.
5 Press the SELECT key again to start the printing of the line test pattern.
6 Evaluate the test pattern to determine if printing is uniformly solid and
crisp. Press the PRINT / PAUSE key at any time to stop printing.
5-12
Press SELECT
Test Print
Test Pattern: = 1 in
Operation
