Check Comm Setup
•
Indicates that data port-specific commands were received via the status
port, causing a communications error. Ensure that the data port is set up
correctly.
Head x up
SELECT to disable
•
Displayed when a printhead x is lifted after the printer has been
powered on. Pressing select will disable this head until the printer power
has been cycled. The following message is displayed after a printhead is
disabled:
Head x Disabled
Printheads Disabled
Hd1
•
Displayed after the self-test when the printer is powered on with one or
more of the heads already lifted. The printer indicates which heads have
been disabled upon power up.
QLS-4100 Xe
Data Port Error
Hd2 Hd3 Hd4
