Cutter Baseline

This function is used to synchronize printing when using multiple
cutters. If you are sending the same image file to two or more printers/cutters
and notice that the cutter cuts in different vertical locations, you can use this
function to move the vertical baseline of a cutter.
Cutter baseline adjusts the position of the cut line with respect to Cut Offset.
Possible values range from -120 to +120 dots.
To adjust the cutter baseline:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Cal & Setup menu is
displayed. Then press the SELECT key.
Pause: Cal & Setup
3 Press the NEXT or PREVIOUS key until the Cutter Baseline menu is
displayed.
4 Press the + or – key until the desired baseline setting is displayed.
Baseline settings range from -120 through +120 dots. Negative values
move the cut line toward the bottom of the tag. Positive values move the
cut line toward the top of the tag.
5 Press the SELECT key to confirm the baseline.
4-30
Press SELECT
Cutter Baseline
Baseline = 0
Keypad controls and menus
