Operating Without Compressed Air

The QLS-4100 Xe RibbonRation ribbon conservation system has been
designed so that the printer can operate normally without compressed air,
but without the advantage of ribbon savings.
If sufficient compressed air is not available during the power up self-test, the
printer will detect this condition and display the following message:
RUN with NO AIR?
Press: Select
Pressing the SELECT key will disable the RibbonRation system until the
power to the unit is cycled and sufficient compressed air is available to the
printer. If this message appears and you do have compressed air connected
to the printer, check the pressure level on the air regulator to ensure that it
meets the minimum 70 psi requirement. Once sufficient air pressure is
available to the printer, this message will disappear and the printer will go to
a Ready state.

Memory Card Detection

The status of the memory card is checked during the power-up sequence. If
the card is working properly, or if no card is inserted, the power-up sequence
will proceed normally. If a problem with the memory card is detected, you
will be given the option to perform a corrective action, which requires the
memory card write protection setting to be off, or remove the card.
If an unformatted memory card is detected, you can format or remove the
card. Refer to the System Menu section of Chapter 4 for more information.
Remove Flash Card or
SELECT to Format it
If the card is missing any required folders, you can press SELECT to add
them, or remove the card. The message "Folders Complete" will appear
when folders are successfully added.
Remove Flash Card or
SELECT to Add Folder
If the card is defective, you will be prompted to remove the card.
QLS-4100 Xe 5-3
