To set printhead intensity via the front panel:
1 If the printer is in a Ready state, proceed to the next step.
If the printer is in a Pause state, press the NEXT or PREVIOUS key until
the Adjust menu is displayed. Then press the SELECT key.
Pause: Adjust
2 Press the NEXT or PREVIOUS key until the Intensity menu for the print
station you want to adjust is displayed.
Note: Head 1 is the station closest to the media exit. Heads 2, 3, and 4 are
positioned sequentially behind head 1.
3 With the desired print station appearing on the display, press the + or –
key until the print intensity setting you want is displayed. Intensity
settings range from 1 to 32.
Note: In most cases, higher intensities result in darker prints. Similarly,
lower intensities generally result in lighter prints.
4 Press the SELECT key to confirm your choice.
4-10
Press SELECT
Intensity
Head 1 = 16
Keypad controls and menus
