Print & Peel Installation
The installation process will vary based on how the system components were
obtained.
•
Complete Print & Peel System - The complete system contains a QLS-
4100 Xe printer with factory-installed custom hardware and the Print &
Peel base. No modifications to the QLS-4100 Xe are necessary.
Refer to Installing the Print & Peel System for installation instructions.
•
Print & Peel Refit - The Print & Peel Base is available separately for
installation on existing QLS-4100 Xe printers (models with Pull Back
option only). In this situation, the printer will require modification prior
to installing the Print & Peel System.
See Refitting an Existing QLS-4100 Xe for QLS-4100 Xe refit instructions.
Then refer to Installing the Print & Peel System for installation instructions.
QLS-4100 Xe 8-5
