QLS-4100 Xe Specifications
Printing Method
Print Stations
Registration Accuracy +/- 0.5 dot typical (0.0015", 40 microns)
Ribbon Management
Resolution
Print Speed
Maximum Print Area
Fonts
Resident Barcodes
Control Panel
Connectivity
Interface Software
Color Halftoning
Memory
B-2
Thermal Transfer, Spot and CMYK Process Color
4 printheads
User selectable, patented RibbonRation™ systems
conserves thermal transfer ribbon automatically
using air-operated cylinders.
300 dpi
2" (50 mm) - 7" (177 mm) per second
Width: 5" (127 mm); Length: 60" (152 cm) with
Windows® Driver; 30" (76 cm) with Custom
QuickLabel
7 TrueType™ fonts resident; other TrueType™ fonts
can be downloaded from your PC
All Standard symbologies, including 2-Dimensional
Ergonomic Key Pad for Menu functions, Backlit
LCD display
PC, AS/400®.
Parallel (IEEE-1284 Centronics), Serial (RS-232),
Ethernet
Windows®-based
Printer Drivers included; Custom QuickLabel
Label Creation Suite (optional)
Printer optimized for MicroCell™ dot placement
algorithm available in Windows® Driver and
Custom QuickLabel software
4 Mb user-available fonts
4 Mb user-available bitmap images
Compact FLASH (Type 1) memory cards
Specifications
