QuickLabel Systems QLS-4100 Operation & Setup Manual page 182

Print & Peel Specifications
Weight
Length
Width
Height
Peel Height
Power Requirements
B-4
Weight of rewind base is 60 lbs.
Total weight is weight of rewind base plus weight of
QLS 4100 Xe plus consumables loaded.
Length (base only): 22.0 inches
Length (base + printer):
QLS-4100 Xe length + 1.85inches
Width (base only): 18.5 inches
Width (base + printer): 18.5 inches.
Additional width needed (left side) to open printer
door for loading of consumables and access
to rewind mandrel for threading of liner.
Height w/feet (base only): 10.630 inches
Height w/feet (base + printer): 33.85 inches
14.66 inches from tabletop
Base only: 120/240 VAC, 50/60 Hz, 0.7A/0.35A
Base and Printer: 120/240 VAC, 50/60 Hz, 6.7A/3.35A
Specifications
