TCP/IP Connections

You will use the TCP/IP Connections option in the Communications menu to
select whether the TCP/IP status socket is enabled. By default, the status
socket is enabled.
Note: If you are using Custom QuickLabel in bidirectional communication
mode, the TCP/IP status socket must be enabled.
For more detailed information on the topic of networking, refer to the
documentation applicable to your network environment and/or contact your
network administrator.
To set the TCP/IP connections option:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Communications menu is
displayed. Then press the SELECT key.
Pause: Communications
3 Press the NEXT or PREVIOUS key until the TCP/IP Connections menu is
displayed.
4 Press the + or – key to change the value.
•
One - If you select this option, the TCP/IP status socket will be
disabled.
•
Two - If you select this option, the TCP/IP status socket will be
enabled.
Note: On some printer models, the port number selection is indicated in
parentheses (2864 or 9100).
5 Press the SELECT key to confirm the TCP/IP connection option.
4-48
Press SELECT
TCP/IP Connections
Two
Keypad controls and menus
