TCP/IP Gateway

You will use the TCP/IP Gateway option in the Communications menu to set
a subnet mask for the QLS-4100 Xe printer.
The default gateway is 0.0.0.0.
Note: For more detailed information on the topic of networking, refer to the
documentation applicable to your network environment and/or contact your
network administrator.
To set the TCP/IP gateway:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Communications menu is
displayed. Then press the SELECT key.
Pause: Communications
3 Press the NEXT or PREVIOUS key until the TCP/IP Gateway menu is
displayed.
4 Press the + or – key to increase or decrease the first number in the
address, then press the SELECT key.
Press the + or – key to increase or decrease the second number in the
address, then press the SELECT key.
Press the + or – key to increase or decrease the third number in the
address, then press the SELECT key.
Press the + or – key to increase or decrease the fourth number in the
address, then press the SELECT key.
5 Press the SELECT key to confirm the TCP/IP gateway.
QLS-4100 Xe
Press SELECT
TCP/IP Gateway
0.0.0.0
4-47
