Quick Start Guide

If you are an experienced user of a QuickLabel Digital Color Printer or you
have attended QuickLabel College training, use this Quick Start Guide as a
reference to begin producing beautiful color labels immediately.
In general, these operations should be performed in the sequence listed
below, skipping over any items that may have been previously completed.
Page 2-2
Page 2-7
Page 2-8
Page 2-9
Page 2-14
Page 3-2
Page 3-4
Page 3-7
Page 3-8
Setup software parameters
Appendix D
Appendix E
QLS-4100 Xe
Unpack the printer
Install the media unwind mandrel
Connect the AC power cord
Connect the host computer interface
Connect the compressed air source
Load thermal transfer ribbon
Load label or tag media
Adjust the media sensor
Calibrate the printer to the appropriate media type
Printing from Custom QuickLabel
Printing from a Windows application with the QuickLabel
Windows Printer Driver
1-3
