RS232 Baud Rate

If you are using the RS232 serial port connection, you can configure the
printer to use one of four specific baud rates.
To select a baud rate:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Communications menu is
displayed. Then press the SELECT key.
Pause: Communications
3 Press the NEXT or PREVIOUS key until the RS232 Baud Rate menu is
displayed.
4 Press the + or – key until the desired baud rate is displayed. Available
options are 4800, 9600, 19200, or 38400.
5 Press the SELECT key to confirm your baud rate choice.
QLS-4100 Xe
Press SELECT
RS232 Baud Rate
19200
4-43
