Replacement Parts
Part Number
14076-001
14039-001
14039-401
14041-101
14039-101
14039-501
14058-000
14057-201
14057-301
23701-211
24034-002
24034-004
13832-000
14050-400
14050-050
14050-500
RN1716
14109-020
14046-200
10609-016
13318-000
00058DA
25747-000
23682-114
14099-000
24878-000
Recommended spare parts are noted in bold.
Parts specifications are subject to change without notice.
Contact QuickLabel Technical Support to identify the correct parts and
obtain current pricing. Please have the serial number of your printer
available.
C-2
Description
Printhead
Drive Roll (black polyurethane)
Drive Roll (blue silicone)
Pinch Roller (aluminum with coating)
Platen Roller (black polyurethane, 60 Dur.,
bearings installed)
Platen Roller (blue silicone, 50 Dur.,
bearings installed)
Bearing Block Assembly (drive roll)
Lever Printhead Lift (4)
Lever Drive Roll Lift
Belt Timing 3mm 211T
Fuse 6.3 A (110VAC)
Fuse 4.0 A (220VAC)
Cleaning Pads (case of 50)
Platen Shaft (4)
Drive Shaft
Drive Shaft Stub
Drive Snap Ring (2)
Collar (9)
Shaft End Plate (5)
#6 Pan Head Philips
Leaf spring bracket for ribbon rewind mandrels
Leaf spring bracket for label & ribbon unwind
mandrels
Motor Assy, Main
Pulley, Drive
Gas Spring, Drive Station
Motor Assy, Thermal Transfer Ribbon (4)
