Cut Flag - QuickLabel Systems QLS-4100 Operation & Setup Manual

Cut Flag

When using an optional cutter or cutter/stacker accessory, it is possible to
enable or disable the insertion of extra blank tags to demarcate or flag the
end of a batch.
When enabled, the printer will automatically insert one long and one short
blank tag between batches. The longer tag is approximately 10 mm longer
than the printed tag length. This extra length will allow you to quickly
identify separate batches. With the flag enabled, the minimum tag length is
38 mm.
To enable or disable the cut flag:
1 If the printer is in a Ready state, press the PRINT/PAUSE key to pause
the printer.
2 Press the NEXT or PREVIOUS key until the Options menu is displayed.
Then press the SELECT key.
Pause: Options
3 Press the NEXT or PREVIOUS key until the Cut Flag menu is displayed.
QLS-4100 Xe
Press SELECT
Cut Flag
Off
4-61
