Table 2-1. Blade Status Page Controls - Supermicro MicroBlade User Manual

Item Control Name
1 Power Off Button
2 Power On Button
3 Power Cycle Button
4 Power Reset Button
Graceful Shutdown
5
Button
6 AC Cycle Button
Power Fail Policy
7
Button
8 Pwr Capping Button
9 AC Lost Policy Button
10 Refresh Button
11 Pwr Status On/Off
12 KVM
13 UID
14 Pwr Fail Policy
15 Pwr Cap
16 AC Lost Policy

Table 2-1. Blade Status Page Controls

Description
Checking the check box next to a node or blade module and then
pressing this button will power off the selected node or blade system.
Checking the check box next to a node or blade module and then
pressing this button will power on the selected node or blade system.
Checking the check box next to a node or blade module and then
pressing this button will initiate the power cycle for the selected node or
blade system.
Checking the check box next to a node or blade module and then
pressing this button will reset the selected node or blade system.
Checking the check box next to a node or blade module and then
pressing this button will initiate a graceful shutdown for the selected
node or blade system.
Checking the check box next to a node or blade module and then
pressing this button will initiate the AC cycle for the selected node or
blade system.
Checking the check box next to a node or blade module, and then
selecting an option from the drop-down list box for the item and then
pressing this button will set the selected power fail policy for the selected
node or blade system.
Checking this button for a selected node or blade module sets power
capping for that node or blade by bringing up a confirmation pop-up.
Checking the button next to a node or blade module, and then selecting
an option from the drop-down list box for the item and then pressing this
button will set the selected AC lost policy for the selected node or blade
system.
Pressing this button will refresh the screen to accurately show the new
status of all blade modules or nodes in the system.
The button in this column allows you to power on or off a node or blade
in the selected row.
Pressing the button in this column for a selected blade or node starts up
a KVM window for viewing that blade or node.
Pressing the button in this column for a selected blade lights up the UID
for that blade.
This column contains a pull-down menu for selecting the Power Fail
Policy for the selected blade or node. Options include T
P O or P
OWER FF ERFORMANCE
This column contains a pull-down menu for selecting the Power Cap for
the selected blade or node. Options include R
percentage values from 50% to 90%.
This column contains a pull-down menu for selecting the AC Lost Policy
for the selected blade or node. Options include P
and L S .
AST TATE
Chapter 2: Blade System
.
2-3
,
HROTTLE
O , D , and
EAD NLY ISABLED
O , P ON
OWER FF OWER
