Chapter 1 Introduction; Network Connection/Login - Supermicro MicroBlade User Manual

The MicroBlade Web-based Management Utility is a web-based interface that
consolidates and simplifies system management for Supermicro MicroBlade systems.
The MicroBlade Web-based Management Utility aggregates and displays data from the
SIMCM (the IPMI card designed for Supermicro's MicroBlade Chassis Management
Module).
The MicroBlade Web-based Management Utility provides the following key
management features:
• Enables IT administrators to view in-depth hardware configuration and status
information using a single intuitive interface.
• Provides an OS-independent, remote graphical console.
• Allows remote users to map local media (floppy, CD-ROM, removable disks and
hard drives) or ISO images on a shared network drive to a blade server.
Supported Browsers
The following browsers have been tested for use with the MicroBlade Web-based
Management Utility. It is recommended that you use the most current revision of the
browser you choose. The minimum browser revisions supported by the MicroBlade
Web-based Management Utility are shown below:
• Internet Explorer 7
• Firefox 2.0.0.7
• Netscape 9.03b
• Google Chrome
1-1

Network Connection/Login

To log into the MicroBlade Web-based Management Utility:
1. Launch a web browser.
2. In the address field of the browser, enter the IP address that you assigned to the
MicroBlade Chassis Management Module (CMM) and hit the <E
3. When the browser makes contact with MicroBlade Chassis Management Module,
enter your username and password, then click L
4. The W -
EB
Figure 1-1.
Chapter 1
Introduction
M
BASED ANAGEMENT
OGIN
U H P
TILITY OME AGE
1-1
NTER
.
will then display as shown in
> key.
