Web-based Management Utility User's Manual
Item Name
Module Selection
1
Drop-down List Box
Module Number
2 Selection Drop-down
List Box
Sensor Selection
3
Drop-down List Box
4 Refresh Button
Show Thresholds
5
Button

Table 3-1. Sensor Readings Page Controls

Description
Select from here the module type whose sensors you wish to view.
Options include: CMM, Blade, Switch or Power Supply.
Select the specific module of the type you selected in the M
S list whose sensors you wish to view.
ELECTION
Select in this drop-down list box the type of sensor you wish to view from
the previous selected module. Options include All Sensors, Temperature
Sensors or Voltage Sensors,
When you have made all your selections, press the A
the sensors.
Press this button to refresh the page.
Pressing this button shows the thresholds for your system.
3-2
ODULE
button to view
PPLY
