Web-based Management Utility User's Manual

4-13 Port Page

Click on P to reveal the P
ORT
configure a port number for your system. The commands you may give on this page, as
described below in
1
3
5
6
Item Control Name
Web Port Number
1
Field
Web SSL Port
2
Number Field
KVM Server Port
3
Number
Virtual Media Port
4
Number
SSL Redirect Enable
5
Check Box
6 Save Button
S
ORT ETTING
Table 4-13.

Figure 4-19. Port Setting Page

2
4

Table 4-13. Port Setting Page Controls

Description
User this field to enter the Web Port number.
User this field to enter the Web SLL Port number.
User this field to enter the KVM Server Port number.
User this field to enter the Virtual Media Port number.
Check this box to enable SSL redirect for your system.
Once you are done configuring your Port Number settings, press this
button to save your configuration.
page (Figure 4-19). Use this page to
4-20
