This addendum addresses European Union (EU) Ecodesign requirements for servers and storage
products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in
the manual. The below information conforms to requirements laid down in Annex II of the Commission
Regulation 2019/424.
3(1)(a):
See Section 1.1 of the system manual for the product type.
3(1)(b):
See the title page and preface of the system manual for the trademark and
manufacturer's address.
3(1)(c):
See the title page of the system manual for product model number(s).
3(1)(d):
See the serial number on the physical system to determine the year of manufacture.
PSU Efficiency and Power Factor Value (Table) (From 80 Plus report)
3(1)(e-j):
PSU Model #: PWS-2K04A-1R
Watts: 2000W
% of Rated Load
Single Output (AC-DC)
System (EUT) Efficiency in
Representative
Configurations
High-End Performance
Configuration
Typical Configuration
Low-End Performance
Configuration
System (EUT) Efficiency in
Representative
Configurations
High-End Performance
Configuration
Typical Configuration
Low-End Performance
Configuration
Information for Lot 9 of ErP (Ecodesign)
For 7048GR-TR
10 %
94.06 %
Idle State
Measured Idle State
Power (W)
297.84
N/A
71.618
Active State
Active State
Efficiency Score
(Effserver)
167.488
N/A
81.417
PSU Efficiency
20 %
50 %
95.75 %
96.30 %
Power (Table)
Calculated Idle Power
Allowance (W)
1309.08
N/A
1233.76
Power (Table)
Minimum Active State
Efficiency for 2-Socket
Server
9.5
Power Factor
100 %
50 %
93.84 %
0.99
