ControlMaster CM10, CM30 and CM50
Universal process controllers,
7 Advanced Level ........................................................ 36
7.1 Device Setup ....................................................... 36
7.2 Display ................................................................ 39
7.3 Input/Output ........................................................ 43
7.4 Control ................................................................ 51
7.5 Process Alarm ..................................................... 63
7.6 Profile .................................................................. 66
7.6.1 Ramp Types .............................................. 67
7.6.2 Guaranteed Ramp / Soak .......................... 68
7.6.3 Set Point Start Condition - Current PV ...... 70
7.6.4 Profile Parameters ..................................... 71
7.7 Functions ............................................................ 80
7.8 Communication ................................................... 93
7.9 Diagnostics .......................................................... 94
7.9.1 Diagnostic Messages ................................ 96
7.10 Device Info ....................................................... 100
8 Templates and Functionality .................................. 101
8.1 Basic Templates ............................................... 101
8.1.1 Single Loop / Single Loop with
Remote Setpoint ..................................... 101
8.2 Standard Templates ......................................... 103
8.2.1 Auto / Manual Station (Low Signal
Selection / Digital Signal Selection) .......... 103
8.2.2 Analog Backup Station (Low Signal
Selection / Digital Signal Selection) .......... 104
8.2.3 Single Indicator ....................................... 106
8.2.4 Dual Indicator ......................................... 106
2
1 1 1
/ , / and / DIN
8 4 2
9 PC Configuration .....................................................107
10 Specification ..........................................................108
Appendix A - Digital and Analog Sources .................116
A.1 Digital Sources ...................................................116
A.2 Analog Sources .................................................117
Appendix B - Error Codes ..........................................118
B.1 Configuration Error Codes .................................118
B.2 Profile Error Codes .............................................121
Appendix C - Analog Input (Engineering) Units ........122
Appendix D - Output Type Assignments ..................124
Contents
IM/CM/S-EN Rev. R
