5-4-1

Enclosure

The EMC enclosure shall house an ATX Power Supply with UPS battery backup, an ATX style
motherboard with minimum of 512 MB of ram and two 733MHz processors
5-4-2 PCI Cards
5 PCI slots on the mother board shall contain the following:
1.) PCI Video Card - Digital Video to the Touch Panel
2.) Sound Card - Sound Blaster Live for audio to speakers
3.) Blank or PCI Bird 3D Card - Option
4.) PC2IP Card - GE designed. PCI Bus interface to the Front End Processor
5.) Network Interface Card - 3Com Ethernet Card
5-4-3 AGP Video Card - SVGA Video to the PCVIC Card
• Analog output shall comply with the SVGA specification.
• Resolution shall be 800x600.
• Support for 32 bit True Color
• Minimum of 8 Mbytes of high speed Video RAM, expandable to at least 16 Mbytes.
• 128-bit internal memory interface.
• Hardware supported asynchronous bit block transfer (80 Mpixels/sec).
• Full Direct 3D and Open-GI support (desirable).
5-4-4 PCIO Board:
This GE designed board does not plug into any slot but is mounted to the inside of the PC chassis.
-
5-4-5 PCVIC Card
-
This GE designed board does not plug into any slot but is mounted to the inside of the PC chassis.
-
-
5-4-6 DGVIC, DGIO and ADD Cards BEP 2.1 (BT'02, November 2002)
The ADD Card is a PCI card that mimics the AGP video and provides a digital video output to the DGVIC
board.
The DGVIC converts the digital video to RGBS, SVGA (to Monitor and External I/O), S-video and
Composite video outputs.
The DGIO provides signals and power to I/O boards. Signals like PS_ON, I
PC On/Off.
5-24
PROPRIETARY TO GE
3
EVISION
Power and Internal PCI control signals
Input from AGP Video card (BEP1.0) or Motherboard AGP Video (BEP 2.0)
SVGA output to the image monitor
RGB output to color printer
