8-2-4

Top Cover Replacement Procedure

8-2-4-1 Manpower
One person, 30 minutes
8-2-4-2 Tools
Phillips Screwdriver
8-2-4-3 Preparations
1.) Power Down/Shutdown the system as described in
2.) Remove both left- and right-side covers as described in
3.) Remove upper rear cover as described in
8-2-4-4 Removal Procedure
1.) Move the Operarttor I/O up and forwards to its end positions.
2.) Unscrew the 10 screws shown in
3.) Pull the cover gently backwards and upwards to free the cover from the hoist area and allow it to
pass freely past the rear handle.
4.) Lift the top cover away from the scanner chassis.
8-2-4-5 Installation procedure
(click here to view the cover installation video)
1.) Position the top cover in place and fasten it with the 10 screws.
2.) Mount the side
3.) If required, Power On/Boot-up the system as described in
8-8
PROPRIETARY TO GE
3
EVISION
Select the movie camera icon to view the video of the Cover
removal procedure.
(Section 8-2-2 on page
Top Cover
Chassis Shelf is
Printer Positioning Shelf
Figure 8-4 Top Cover
Section 8-2 - Plastic Covers and Bumpers
Section 4-3-2 on page 4-3
Section 8-2-2-4 on page
Section 8-2-3 on page
Figure 8-4 on page 8-8 .
8-5) and upper rear
Section 4-3-1 on page 4-2
LOGIQ™ 9 P
ROPRIETARY
8-5.
8-7.
(Section 8-2-3 on page 8-7) covers.
Screws (10)
