8-2-2-5

Side Cover Installation Procedure

(click here to view the cover installation video)
1.) Guide the top edge of the side cover so the hooks rest in the top cover retainer slots.
2.) Push back side in first position so it is locked in Lower Rear Cover.
2
3.) Push the front side in position so it is locked in Front Cover.
4.) With a large coin, turn the two bottom fasteners to the vertical position.Now, using a large
screwdriver, push in on these fasteners to lock them in place.
5.) If required, Power On/Boot-up the system as described in
8-6
PROPRIETARY TO GE
3
EVISION
1
3
4
Figure 8-2 Installation of Side Covers
Section 8-2 - Plastic Covers and Bumpers
LOGIQ™ 9 P
ROPRIETARY
Side Cover hooks
Top Cover slots
Power On / Boot Up on page
M
ANUAL
4-2.
