Verify and Update Vital Product Data

8-35-1 Introduction
It is essential that Vital Product Data (VPD) is verified or updated after any hardware change to the Back
End or Front End Processors.
NOTE: Failure to properly program Vital Product Data could cause adverse affects on system
operation and image quality.
The items of concern are:
-
-
8-35-2 Collecting Vital Product Data
For the Back End Processor, remove the system left side cover and read the label on the front of the
processor. The Part Number is there. The Functional Revision is the PSP# (number) on the label. Get
the date for the BEP from this BEP rating plate. All other dates are taken from the Console rating plate.
If the VPD Read Utility
no data for the Equalization Board (EQ), obtain that data by removing the system right side cover,
remove the FEP cover, remove the EQ Board and obtain the data indicated in
Table 8-9
Circuit Board Name
BEP
Table 8-10
Circuit Board Name
Equalization
PROPRIETARY TO GE
3
EVISION
Verify that the Board or BEP Vital Product Gata is programmed
Program the new Board or BEP Vital Product data. (BEP VPD is stored on the FEP
backplane).
(8-35-3-3 "Acquisition Diagnostics - Read EEPROM Data" on page
BEP VPD Data
Functional Revision
Part Number PWA Letter
BEP Rating Plate PSP Revison
Typical Circuit Board VPD Data
Functional Revision
Part Number PWA Letter
2260210
Chapter 8 Replacement Procedures
LOGIQ™ 9 P
Bar Code or
Fab Revision
PWB Number Serial Number
No Dash Allowed
N/A
Bar Code or
Fab Revision
PWB Number Serial Number
M
ROPRIETARY ANUAL
8-138) shows
Table 8-9.
Date
YYYYMMDD
BEP Rating Plate
2 0 0 _ _ _ 01
Date
YYYYMMDD
2 0 0 _ _ _ 01
8-135
