Side Covers (With Bumper) Replacement Procedure - GE LOGIQ 9 Technical Manual

GE M S
EDICAL YSTEMS
D 2294854-100, R
IRECTION
8-2-2

Side Covers (with Bumper) Replacement Procedure

8-2-2-1 Manpower
One person, 5 minutes
8-2-2-2 Tools
Large coin and a large screwdriver
8-2-2-3 Preparations
Power Off / Shutdown the system as described in
8-2-2-4 Side Cover Removal Procedure
1.) Use a large coin to turn the two recessed fasteners at the bottom of the side cover a quarter turn to
the horizontal position.
2.) Take hold under the lower front side of cover and pull out gently. At the same time support the rear
side of the cover with the other hand.
NOTE: The two fasteners hold the left-side cover to the scanner at the bottom of the card cage cover.
The two fasteners hold the right-side cover to the scanner at the bottom of the AC power supply wall.
3.) When the cover is loose in front, pull the rear out and move upwards.
4.) Lift the side cover gently upwards until the three hooks at the top of the side cover are free from the
three retainer slots in the top cover as shown in
5.) To Remove Left side cover, repeat this procedure.
NOTE: Figure 8-1
the left-side cover.
PROPRIETARY TO GE
3
EVISION
Select the movie camera icon to view the video of the Cover
removal procedure.
shows the right-side cover being removed. Repeat the same steps listed above to remove
Recessed1/4 turn fasteners
Pull front side loose first
Figure 8-1 Removal of Side Covers
Chapter 8 Replacement Procedures
Section 4-3-2 on page
Figure 8-1.
Coin
LOGIQ™ 9 P
ROPRIETARY
4-3.
M
ANUAL
8-5
