Procedure Call - ASCOM d81 Messenger User Manual

User Manual
Ascom d81 DECT Handset
9

Procedure Call

When configuring the functions Call services
service to the Phone call function; the data added in these functions is static. When entering
the data for the function to be used, it is possible to add a variable/character U that allows
the user to enter additional numerical characters before calling the number/sending the
data to a system.
See the following example for more information.
Example of configuration:
A user wants to create a service with the Phone call function. The PBX requires that a prefix
must be added to a phone number. In this case, the user can pre-program the prefix and
then enter the applicable phone number when using the Phone call function.
1 Press "Menu", or the confirmation button.
2 Select "Services".
3 Select "Add new".
4 In the Name field, enter "Call no.".
5 Select the function "Phone call".
6 In the Number field, enter the prefix to be used followed by the character "U". In this
case, the text string is as follows *21*U. The character U represents an Enter number
dialog where the user can enter the phone number.
7 Press "Save".
When using the function, an Enter number dialog appears, see figure below. If the user
enters "123" (or selects a contact with this number by pressing
the number *21*123 will be dialed. Note that no call is established before the user presses
"OK", that is, post-dial.
OK
Figure 9. Enter number dialog.
27.Configuration of this function requires PDM/Device Manager.
08 June 2012 / Ver. D
Figure 8.
13:00
Services
Enter number:
123
Back
27 21
, In Call menu , Contacts, or a shortcut/
TD 92644EN
) and presses "OK",
76
