CDM-550T Satellite Modem
KST-2000A FSK Remote Operation
1.2

Menu Trees

1.2.1

SELECT

SELECT: CONFIG TEST INFO
MONIT
The user is presented with the following choices:
CONFIG
TEST
INFO
MONIT
STORE/LD
UTIL

ODU

The first six items are covered in the existing modem manuals. The ODU item is
now described in detail.
1.2.2 ODU
DISABLE
ENABLE
MN/CDM550T.AA1
STORE/LD UTIL ODU
(Configuration) This menu branch permits the user to fully configure the modem.
This menu branch permits the user invoke one of several modem test modes
(loopbacks, for example).
(Information) This menu branch permits the user to view information on the modem,
without having to go into configuration screens.
(Monitor) This menu branch permits the user to monitor the alarm status of the
modem, to view the log of stored events, and to display the Receive Parameters
screen.
(Store/Load) This menu branch permits the user to store and to retrieve up to 10
different modem configurations.
(Utility) This menu branch permits the user to perform miscellaneous modem
functions, such as setting the Real-time clock, adjusting the display brightness, etc.
(Outdoor Unit) This permits the user to monitor and control a Comtech EF Data KST-
2000A Transceiver, if connected.
TRANSCEIVER CONTROL:
DISABLE ENABLE
This menu item turns OFF the FSK link to the ODU
This menu item turns ON the FSK link to the ODU
(ENTER)
