Front Panel Operation
(CONFIG, TX, PWR) MODE
6–10
OUTPUT POWER LEVEL MODE:
MANUAL AUPC
Select the output power level mode, either Manual or AUPC, then press ENTER.
If the user selects MANUAL, the following menu is displayed:
(CONFIG, TX, PWR, MODE) MANUAL
EDIT OUTPUT POWER LEVEL:
-03.9 dBm (PRESS ENTER)
Edit the output power level, then press ENTER.
If the user selects AUPC, and 'Framed' mode is not selected, the following menu
is displayed:
(CONFIG, TX, PWR, MODE) AUPC
WARNING! AUTO UPLINK PWR
CONTROL NEEDS FRAMED MODE
Pressing either ENTER or CLEAR returns the user to the previous menu with
MANUAL selected.
If the user selects AUPC, and 'Framed' mode is selected, the following menu is
displayed:
(ENTER)
CDM-550T Satellite Modem
Rev. 1.3
