Front Panel Operation
MONIT) STATS (Link Statisics)
(MONIT, STATS) VIEW
6–36
If the user selects STATS, the following sub-menu is displayed:
LINK STATISTICS:
CLEAR
CONFIGURE (ENTER)
Select VIEW, CLEAR, or CONFIGURE, using the LEFT/RIGHT arrow keys,
then press ENTER.
If the user selects VIEW, the following screen is displayed:
STA198:02/11/00 10:37:32
16.0,16.0,9.0,9.0(UP/DN)
The user may scroll backwards or forwards through the entries in the statistics
log, using the UP/DOWN arrow keys. Pressing ENTER or CLEAR will take the
user back to the previous menu. The event log can store up to 250 events.
The top line of the display indicates the log entry number, and the time and date
of the entry. Note that in accordance with international convention, the date is
shown in DAY-MONTH-YEAR format.
The bottom line of the display shows the statistics data which has been measured
and recorded.
The meaning and format of the numbers is as follows:
Minimum Eb/No, Average Eb/No, Maximum TPLI, Average TPLI
(where TPLI means Transmit Power Level increase, if AUPC is enabled).
The user defines a measurement interval (see MONITOR, STATS,
CONFIGURE) and during this interval, Eb/No and TPLI are observed, at a one
second rate. At the end of this period, the average Eb/No is calculated and
recorded, and the minimum value seen in the interval. Similarly, the average
TPLI is calculated, along with the highest value seen in the interval.
CDM-550T Satellite Modem
VIEW
Rev. 1.3
