Remote Control
Parameter Command
Type (InstructionC
ode and
qualifier)
AUPC APP=
Parameters
Remote N/A
Eb/No
Tx Power N/A
level
Increase
15–14
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is,
Response to ASCII codes between 48 and 57)
Query
6 bytes, Command or Query.
Defines AUPC (Automatic Uplink Power Control) operating
parameters. Has the form abc.cd Where:
a = Define action on max power condition:
0 = do nothing
b = Define action on remote demod unlock:
0 = go to nominal power 1 = go to max power
c.c = Target Eb/No value, in dB, for remote demod
d = Maximum increase in Tx Power permitted, in dB
Example: APP= 015.67
4 bytes, Query only. (AUPC feature)
numerical Returns the value of Ebi/No of the remote demod, if Framing
is enabled.
Returns 99.9 if demod is unlocked.
Returns xx.x if Framing is not enabled.
Range: between 2 and 16dB. Resolution 0.2 dB.
Example: REB=12.4 (which is Eb/No = 12.4 dB)
For values > 16.0 dB, the reply will be REB=16.0
3 bytes, Query only. (AUPC feature)
numerical Returns the increase in Tx power level, in dB (from the
nominal setting) due to the action of AUPC.
Returns x.x if AUPC is not enabled.
Example: PLI=2.3
1 = generate TX alarm
CDM-550T Satellite Modem
Response to Command Query
(target to controller) (Instruction
Code and
qualifier)
APP= (message ok) APP?
APP? (received ok,
but invalid arguments
found)
APP* (message ok, but
not permitted in current
mode)
N/A REB?
N/A PLI?
Response to query
(target to controller)
APP=abc.cd
(same format as
command arguments)
REB=xx.x
(see description for
details of arguments)
PLI=x.x
(see description for
details of arguments)
