CDM-550T Satellite Modem
6.2.6

MONIT (Monitor)

MONITOR:ALARMS RX-PARAMS
STORED-EVENTS STATS AUPC
Select ALARMS, RX-PARAMS, STORED EVENTS, STATS, or AUPC or using the
LEFT/RIGHT arrow keys, then press ENTER.
If the user selects ALARMS, the following sub-menu is displayed:
6.2.6.1 (MONIT) ALARMS
(MON, ALARMS) UNIT (Unit alarms)
Rev. 1.3
LIVE ALARMS:
RECEIVE
Select UNIT, RECEIVE or TRANSMIT, using the LEFT/RIGHT arrow keys,
then press ENTER.
Depending on the choice selected, one of the following menus will be displayed:
UNIT FAULT: -12 VOLT PSU
IS UNDER-VOLTAGE
The screen will indicate if there are any Unit Faults. If not, it will display
'NONE'. Pressing ENTER takes the user back to the previous menu.
UNIT
TRANSMIT
Front Panel Operation
6–33
