CDM-550T Satellite Modem
6.2.6.3 (MONIT) STORED EVENTS
(MON, EVENTS) VIEW
Rev. 1.3
If the user selects STORED EVENTS, the following sub-menu is displayed:
STORED EVENTS:
CLEAR ALL (PRESS ENTER)
Select VIEW or CLEAR ALL, using the LEFT/RIGHT arrow keys, then press
ENTER.
If the user selects VIEW, the following screen is displayed:
LOG23: 30/11/97 10:37:32
FT - DEMOD LOCK (UP/DWN)
The user may scroll backwards or forwards through the entries in the event log,
using the UP/DOWN arrow keys. Pressing ENTER or CLEAR will take the user
back to the previous menu. The event log can store up to 100 events. When a
fault condition occurs, it is time-stamped and put into the log. Similarly, when
the fault condition clears, this is also recorded, as shown below:
LOG24: 30/11/97 10:37:35
OK - DEMOD LOCK (UP/DWN)
If the user selects CLEAR ALL, the event log is cleared, and the user is taken
directly back to the previous menu. However, if there are faults present on the
unit at this time, they will be re-time-stamped, and new log entries will be
generated.
Note that in accordance with international convention, the date is shown in DAY-
MONTH-YEAR format.
VIEW
Front Panel Operation
6–35
