Comtech EF Data CDM-550T Manual page 69

CDM-550T Satellite Modem
6.2.7.1 (STORE/LD) STORE
Rev. 1.3
STORE CONFIGURATION TO
LOCATION: 10
Select the location to store the current configuration to, using the UP/DOWN
arrow keys, then press ENTER. Locations 1 through 10 are available.
If the selected location does not contain a previously stored configuration, the
following screen is displayed:
YOUR CONFIGURATION HAS
BEEN STORED!
Pressing ENTER or CLEAR will take the user back to the previous menu.
If, however, the selected location contains a previously stored configuration, the
following screen is displayed:
WARNING! LOC 10 CONTAINS DATA!
OVERWRITE? NO
Select NO or YES using the LEFT/RIGHT arrow keys, then press ENTER.
Selecting YES will overwrite the existing configuration at the selected location.
Selecting LOAD will display the following screen:
(ENTER)
(ENTER)
YES
Front Panel Operation
6–39
