CDM-550T Satellite Modem
KST-2000A FSK Remote Operation
1.2.23 (ODU,ENABLE,INFO)
TX: ON
AGC: OFF
This window provides the KST-2000A Transmitter information including Tx
Frequency, and Tx Attenuation, press <ENTER>or <CLEAR>.
1.2.24 (ODU,ENABLE, INFO)
This window provides the KST-2000A Receiver information including Rx
Frequency, and Rx Attenuation, press <ENTER>.
1.2.25 (ODU,ENABLE, INFO)
1.2.26 (ODU,ENABLE, INFO)
This window provides the current configuration of the LNA functions, press
<ENTER>.
1.2.27 (ODU,ENABLE,INFO)
1.2.28 (ODU,ENABLE,INFO)
ASSEMBLY INFO:
AS: 11565-4
Note: The blinking cursor is on the M&C. Use the [↑] [↓] keys to view additional
assembly and S/N information for the Up Converter, Down Converter, and HPA.
MN/CDM550T.AA1
14500.0 MHz
RX: 10950.0 MHz
REF:228
HPA = ON
FAULT LOGIC = NO SUMMARY
LNA: ON
FAULT LOGIC: NO SUMMARY
EQUIP-TYPE: KST-2000A
HPA-TYPE: CEFD-SSPA
M&C
SN: 001370891
TRANSMITTER
19dB
RECEIVER
15dB
HPA
LNA
EQUIP (Equipment)
ASSEMBLY+SN
9
Revision 0
MN/CDM550T.AA1
