Comtech EF Data CDM-550T Manual page 42

Front Panel Operation
(CONFIG, TX, PWR, MODE, AUPC) ALARM
(CONFIG, TX, PWR, MODE, AUPC) DEMOD-UNLOCK
6–12
SELECT ACTION AT MAXIMUM
TX POWER: NONE
Select the action that will occur if the AUPC causes the maximum output power
level to be reached, either NONE or TX ALARM. Then press ENTER.
ACTION WHEN REMOTE DEMOD
UNLOCKS: NOM-PWR MAX-PWR
Select the action that will occur if the remote demod is unlocked. The choices
are: NOM-PWR (Nominal Power), where the ouput level will revert to the
nominal power level set under MANUAL, or MAX-PWR, (Maximum Power),
where the ouput level will change to the maximum permitted. The user should
then press ENTER.
TX ALARM
CDM-550T Satellite Modem
Rev. 1.3
