KST-2000A FSK REMOTE
OPERATION
1.1 ODU Operation via a CDM-550T Modem Front Panel Comprising
Firmware ≥ ≥ ≥ ≥ 1.20
This addendum incorporates the menus that are displayed on the CDM-550T
modem's front panel for control of monitoring and control of the KST-2000A
Satellite Terminal.
The user can fully control and monitor the operation of Comtech EF Data's KST-
2000A Satellite Terminal from the front panel, using the keypad and display of a
CDM-550T modem. Nested menus display all available options and prompt the
user for required actions.
The display has two lines each of 24 characters. On most menu screens, a
flashing solid block cursor blinks once per second to indicate the currently
selected item, digit, or field. Where this solid block cursor would obscure the item
being edited (for example, a numeric field) the cursor will automatically change to
an underline cursor.
MN/CDM550T.AA11
