CDM-550T Satellite Modem
Parameter Command
Type (InstructionC
ode and
qualifier)
Global MGC=
Configuration
Rev. 1.3
Arguments for Description of arguments
Command or (note that all arguments are ASCII numeric codes, that is,
Response to ASCII codes between 48 and 57)
Query
78 bytes, with Command or Query. Global configuration of unit, in the form:
numerical FFF.FFFFDDDD.DDDGRMVSPP.PCX
entries, fixed fff.ffffdddd.dddgrmvswwctt.tbIOTZAAAAAUEEEEBYYY.Y
value entries, YW, where:
and delimiters F = Tx Frequency - same as TFQ= (8 bytes)
D = Tx Data Rate - same as TDR= (8 bytes)
G = Tx FEC Coding type - same as TFT= (1 byte)
R = Tx FEC Code Rate - same as TCR= (1 byte)
M = Tx Modulation - same as TMD= (1 byte)
V = Tx Spectrum Invert - same as TSI= (1 byte)
S = Tx Scrambler State - same as TSC= (1 byte)
P = Tx Power Level - same as TPL= (4 bytes)
C = Tx Clock Source - same as TCK= (1 byte)
X = Tx Carrier Status - same as TXO= (1 byte)
f = Rx Frequency - same as RFQ= (8 bytes)
d = Rx Data Rate - same as RDR= (8 bytes)
g = Rx FEC Decoding type - same as RFT= (1 byte)
r = Rx FEC Code Rate - same as RCR= (1 byte)
m = Rx Modulation - same as RMD= (1 byte)
v = Rx Spectrum Invert - same as RSI= (1 byte)
s = Rx De-scrambler - same as RDS= (1 byte)
w= Rx Sweep Width - same as RSW= (2 bytes)
c = Rx Clock Mode - same as RCK= (1 byte)
t = Eb/No Alarm Point - same as EBA= (4 bytes)
b = Rx Buffer Size - same as RBS= (1 byte)
I = Unit Interface Type - same as ITF= (1 byte)
O =Unit Framing Mode - same as FRM= (1 byte)
T = Unit Test Mode - same as TST= (1 byte)
Z = Unit IF Impedance - same as IMP= (1 byte)
A = Alarm Mask - same as MSK= (5 bytes)
U= ODU Comms - same as ODU= (1 byte)
E= EDMAC Slave address - same as ESA= (4 bytes)
B= AUPC enable - same as AUP= (1 byte)
Y = AUPC setup - same as APP= (6 bytes)
W =Stats log interval- same as SSI (1 byte)
Example:
MGC=074.56780064.0001720112.720082.65430
128.0002320116109.81211100000102361115.659
Response to Command Query
(target to controller) (Instruction
Code and
qualifier)
MGC= (message ok) MGC?
MGC? (received ok,
but invalid arguments
found)
Remote Control
Response to query
(target to controller)
MGC=FFF.FFFFDDD.
DDDRMVSPP.PCXfff.
ffffddd.dddrmvswwctt.t
bIOTZAAAAAUEEEE
BYY
Y.YYW
(same format as
command arguments)
