Front Panel Operation
6.2.5.6 (INFO) REMCONT (Remote Control information)
6.2.5.7 (INFO) MASK (Alarm mask information)
6.2.5.8 (INFO) MISC (Miscellaneous information)
6–32
REM-CONTROL:ON RS485-4W
ADDRESS: 0001 19200 BAUD
This screen shows if the unit is in LOCAL or REMOTE mode, and gives details
of the electrical interface type selected, the unit's address, and the baud rate
selected. Pressing ENTER takes the user back to the previous menu.
ALARMS MASKED:
RX-AIS
This shows, in the same format as the CONFIG, MASK sub menu, which alarms
are currently masked. If an alarm is not masked, a blank is displayed in the
relevant screen position.
MISC: IF-LOOP 50 OHMS
1:1 LINK IDLE
This screen shows the following:
Test mode
IF impedance
1:1 link status - if the CRS-100 1:1 module is being used, this shows the
status of the serial link between the two units.
Redundancy status - either online or standby (1:1 or 1:N)
Pressing ENTER takes the user back to the previous menu.
TX-AIS
ONLINE
