Chapter 6:
Link Configuration
Chapter Contents
This chapter is divided into two sections covering the two phases of Link configuration:
1. Link establishment: Initial setup
2. Link maintenance: Fine tuning and special functions
Link establishment is typically a once‐only task. Link maintenance is required for fine‐tuning
the link and configuration of special features such as VLAN, Quality of Service and more.
Link Establishment
Link Configuration Workflow
The workflow required to establish a link derives from the precedents of the RADWIN 2000 C
Plus family in the RADWIN 5000 Point to Multipoint technology.
As supplied, both ODUs are factory pre‐configured as HSUs. One of them, typically the one to
which you logged on in the previous chapter, must be defined as Link Master ODU.
The Link Master ODU requires activation. The ODU will commence transmitting and receiving
packets related to link management only ‐ that is no service. Activation and Deactivation are
effected quite simply by clicking a toggle button.
Assuming that the ODU intended as Link Slave ODU is mounted aligned and powered up, it
will discover the Master ODU establishing a link for management only. At this point the Slave
ODU may be managed over the air.
Having Identified the Link Slave ODU, the latter must be registered to the Master ODU to
enable traffic between them, completing phase 1.
Following registration, you can set separately,
• MIMO mode
• Transmission ratio between uplink and downlink
RADWIN 2000 C Plus User Manual Release 3.5.70 6‐1
