Two Ways to Run Spectrum View
Two Ways to Run Spectrum View
Spectrum View may be run from the Master in which case you have a choice of analyzing
both sites in the link in one run, or choosing just one.
Spectrum View may also be run on a managing computer directly connected to the Slave.
Remember that in such a case the results will be quite different if the Slave is already part of a
link (registered or not) or if it is completely stand‐alone, for example using a different spectral
range and operating Band from the Master. In the former case, expect a "noise hump" around
the channels used by the link, due to the duty signals from the Master.
Where is the Spectrum View Data stored
Spectrum View data is always stored in the ODU originating the analysis. The Master
maintains the last Spectrum View analysis data for both members of the link. If you run
Spectrum View from a directly connected ODU, it stores its own data, which may be quite
different from the analysis obtained for the same Slave from the Master.
Spectrum View Main Window
In this section we review the main window management controls.
From the Tools tab, choose Spectrum View.
The Spectrum View main window opens in full screen mode:
