Master ODU Unit
» Inter & intra site sync to reduce self interference
» Long range – up to 40 km/25 miles
» Wide range of frequency bands ‐ 3.3‐3.8GHz, 4.9 ‐6.0GHz
» Dedicated Bandwidth ensuring SLA & latency
» Low and constant latency – min < 3ms
» Channel bandwidth – 5/10/20/40 MHz
» Regulations supported ‐ FCC/IC/ETSI/WPC/MII/Universal
» Multiband ODUs: 3.3‐3.8 or 4.9‐6.0 in the same unit
» Simple to deploy
» Web Interface for link management (both Master ODU and Slave ODU)
» SFP support when connecting to a IDU‐H in place of a PoE device
Master ODU Unit
» High capacity ODU
» 250 Mbps aggregate throughput
» Fully integrated with RADWIN Legacy solutions:
• Coexist (HBS‐collocatable) with RADWIN 2000 and RADWIN 5000 products
• Common RADWIN Manager
• Common RNMS
Slave ODU
» High capacity: 5/10/25/50/100 Mbps aggregate throughput
» Separate uplink and downlink configurable Maximum Information Rate (MIR)
Components of a RADWIN 2000 C Plus Link
Major Components
The major element of each site is the ODU radio transceiver. The ODU actually contains two
radios, which may be connected to a dual pole integrated or external antenna. The ODU itself
is connected to a PoE device. The PoE provides an Ethernet LAN connection to user
equipment (typically a switch).
Accessories
To build a RADWIN 2000 C Plus link you will require some of the following accessories:
• PoE devices ‐ Both Gigabit and 100 Mbps
• HSS unit ‐ Collocation unit for intra‐site synchronization
• IDU‐H Aggregation unit for a collocated hub site instead of multiple PoE devices
RADWIN 2000 C Plus User Manual Release 3.5.70
Chapter 2
2‐2
