Telnet Access to the Slave ODU
Telnet Access to the Slave ODU
The procedure is the same as for the Master ODU.
Figure 6‐26: Telnet Management window ‐ Slave ODU
Supported Slave Telnet commands are shown in Table 6‐8 to Table
Table 6‐8: Slave ODU Telnet ‐ Display Commands
Command
display inventory
display management
display link
display ethernet
display ethernet_errors
display ntp
display PM <interface:AIR,LAN1>
<interval:current,day,month>
display bands
Table 6‐9: Slave ODU Telnet ‐ Set Immediate Commands
Command
set ip <ipaddr> <subnetMask>
<gateway>
set trap <index:1‐10> <ipaddr>
<port:0‐65535>
set readpw <oldpasswd> <passwd>
RADWIN 2000 C Plus User Manual
Explanation
Displays ODU product name, Name, Location,
hardware and software revisions, uptime, MAC
address.
Displays IP, subnet, Gateway, Traps table
Displays all static details about the HSU
Displays Port table (State, Status and action)
Displays Cable statistics
Displays Time, Server and Offset
Shows the performance monitor tables for each
interface according to user defined monitoring
intervals
Displays available bands
Explanation
Set the ODU IP address, subnet mask and gateway.
The user must reset the ODU after the command
completion
Set a specific trap from the traps table (e.g. set trap 3
192.168..101 162)
Set the read access password (Read Community)
Release 3.5.70
Chapter 6
6‐10.
6‐41
