Chapter 19:
Spectrum View
What is Spectrum View
The RADWIN Manager Spectrum View utility is an RF survey tool designed to support the link
installation prior to full link service activation. The tool provides comprehensive and clear
spectral measurement information enabling easier, faster and better quality installations.
You can view real‐time spectrum information, save the spectral information and view
retrieved spectral information from historic spectrum scans.
Separate information is generated for the Slave and Master ‐ all by selection.
RADWIN's spectrum measurement and estimation algorithms are designed to show accurate
information accommodating variations in frequency, temperature and interference power
and at the same time overcoming anomalies that tend to occur in high interference
environments.
Who needs it
As indicated in the previous paragraph, Spectrum View is primarily a professional tool for the
technician. The Spectrum View reports may be generated as images, CSV files or text files as
part of the Get Diagnostics feature. All of these are intended for use by to RADWIN Customer
Service to assist with diagnosing interference related problems.
Scope of this Chapter
In view of the nature of the intended audience, we assume that the reader knows about RF
Spectrum Analysis. This chapter therefore, is not a tutorial on RF Spectrum Analysis and is
restricted to showing how to use the Spectrum View tool without any further theoretical
explanations.
RADWIN 2000 C Plus User Manual Release 3.5.70 19‐1
