Port Functionality
Ingress Direction
Table 13‐1: Port settings ‐ Ingress direction
The port 'does nothing' with regard to VLANs ‐ inbound frames are left
Transparent
untouched.
Frames entering the HSU port without VLAN or QinQ tagging are tagged with
VLAN ID and Priority
already tagged at ingress are not modified and pass through.
Tag
Frames entering the HSU port are tagged with provider's VLAN ID and
Priority which are preconfigured by the user. Frame.s which are already
tagged with Provider tagging at the ingress are not modified and passed
through
Provider tag
.
Priority Code Point (PCP) which refers to the IEEE 802.1p priority. It indicates the frame priority level
a.
from 0 (lowest) to 7 (highest), which can be used to prioritize different classes of traffic (voice, video,
data, etc).
RADWIN 2000 C Plus User Manual
a
, which are preconfigured by the user. Frames which are
Release 3.5.70
Chapter 13
13‐3
