Protection Against Lightning
• Ensure that all other cables are disconnected before disconnecting the ground
Protection Against Lightning
The use of lightning protection is dependent on regulatory and end user requirements. All of
RADWIN outdoor units are designed with surge limiting circuits to minimize the risk of
damage due to lightning strikes. RADWIN recommends the use of additional surge arrestor
devices to protect the equipment from nearby lightning strikes.
General
• It is recommended that installation of outdoor units be contracted to a professional
installer
• Before working on equipment connected to power lines or telecommunication lines,
you should remove jewelry or any other metallic object that may come into contact
with energized parts
• Use extreme care when installing antennas near power lines
• Use extreme care when working at heights
• When using an AC power source for RADWIN devices, always use the AC power adapter
supplied by RADWIN
• Use the right tools!
• Do not mount an ODU upside down or horizontally. Doing this may void you product
warranty.
Internal ESD Protection circuits
RADWIN equipment is designed to meet the ETSI/FCC/Aus/NZ/CSA EMC and Safety
requirements. To fulfill these requirements, the system's Telecom lines at the ODU/PoE are
Transformer‐isolated and include internal ESD (Electro‐Static‐Discharge) Protection circuits.
Hardware Installation Workflow for a RADWIN
2000 C Plus link
Installing a Link
Site Survey
The Site Survey is carried out as described in Chapter 3. Recall that the Site Survey has three
main steps:
• Stage 1: Preliminary Survey
• Stage 2: Physical Survey
• Stage 3: RF Survey
RADWIN 2000 C Plus User Manual Release 3.5.70
Chapter 4
4‐11
