Chapter 7:
Site Configuration
Site Tool Bar
Here again are the site tool bars and their functions:
Figure 7‐1: Site Tool Bars
Table 7‐1: Site Buttons - Description
Applies
Menu Button
to site
Both
Both
Both
HBS
HBS
HSU
HSU
HSU
RADWIN 2000 C Plus User Manual
Purpose / Reference
Open the Site Configuration Window
Recent Events
Active Alarms
Deactivate Master ODU
Reset Master ODU, Reset Slave ODU
Deregister Slave ODU
Suspend a Deregistered Slave ODU
Reset Master ODU, Reset Slave ODU
