Site Configuration Tool Bar
Site Configuration Tool Bar
Backup and Restore
The Backup and Restore buttons provide for backup and restore of the ODU software.
A backup (full or configuration) may be restored to another ODU provided
that the product IDs and revision levels of the source and target ODUs are
identical. They are shown in the ODU Inventory window.
In addition, the supported bands and AES version (128 or 256) must be the
Note
same for the source and restored ODUs.
Both buttons open standard MS Windows file dialogs respectively to create and read a file.
The file is store using a proprietary binary format.
Buzzer
The Buzzer button may set or mute the buzzer.
The buzzer tone is primarily used for ODU antenna alignment. It is of limited value in an nLOS
or NLOS link. The default setting is Auto.
Refresh
The Refresh button restores the current window to its previous state abandoning any changes
you made, provided that you did not click Apply or OK.
Deactivate Master ODU
Deactivating the Master ODU halts traffic over the link and drops it back to the default
transmission mode prior to configuration with one exception: The Slave ODU remains
"registered" but inaccessible over the air. You can reactivate the Master ODU without need to
re‐register the Slave ODU. All of the Slave ODU configuration settings are preserved.
Deregister Slave ODU
Deregistering the Slave ODU stops link traffics but leaves it accessible over the air from the
Master ODU. All of the Slave ODU tool bar functions are available.
RADWIN 2000 C Plus User Manual Release 3.5.70
Chapter 7
7‐19
