Radwin 2000 C PLUS User Manual page 260

Private MIB Parameters
Table C‐2: Private MIB Parameters (Sheet 22 of 32)
Name
winlink1000IduSrvAvailServicesRea
son
winlink1000IduSrvEthActive
winlink1000IduSrvEthAvailable
winlink1000IduSrvEthThroughput
winlink1000IduSrvEthMaxInfoRate
winlink1000IduSrvAvailableTrunksT
1
winlink1000IduEthernetIfTable
winlink1000IduEthernetIfEntry
winlink1000IduEthernetIfIndex
winlink1000IduEthernetIfAddress
winlink1000IduEthernetNumOfLan
Ports
winlink1000IduEthernetNumOfSfpP
orts
winlink1000IduEthernetSfpProperti
es
winlink1000IduEthernetGbeSuppor
ted
winlink1000IduEthernetOduInError
s
winlink1000IduBridgeTpAging
winlink1000IduTdmTxClockAvailStat
es
winlink1000IduTdmTxClockDesiredS
tate
winlink1000IduTdmTxClockActualSt
ate
RADWIN 2000 C Plus User Manual
OID Type
Release 3.5.70
Description
RO Information about the TDM Service availability.
‐ Not Applicable if the service is available. The
reasons for TDM Service unavailability: ‐ The
available throughput isn't sufficient for Service
demands; ‐ The IDU HW doesn't support the
service; ‐ A Link Password mismatch was
detected; ‐ The external pulse type detected is
improper for TDM services; ‐ A Software
versions mismatch was detected. ‐ A‐Symetric
TDD Mode Is Obligated.
RO Represents the Ethernet service activation state.
RO Represents the Ethernet service availability
state.
RO Current available Ethernet service throughput in
bps.
RW Holds the maximum bandwidth (kbps) to be
allocated for Ethernet service. Value of zero
means that Ethernet service works as best
effort. The maximum value is product specific.
Refer to the user manual.
RO A bitmap describing the TDM trunks that can be
opened under T1 configuration. The values
take into account the IDU hardware
configuration the air rate and the installation
range.
N/A IDU Ethernet Interface table.
N/A IDU Ethernet Interface table entry. INDEX {
winlink1000IduEthernetIfIndex }
RO If Index corresponding to this Interface.
RO IDU MAC address.
RO Number of LAN interfaces in the IDU.
RO The number of SFP interfaces in the IDU.
RO SFP venfor properties : Vendor Name PN and
Revision.
RO Supported Giga bit Ethernet in IDU.
RO The number of inbound packets that contained
errors preventing them from being deliverable
to a higher‐layer protocol.
RW Timeout in seconds for aging. Note that for this
parameter to be effective the ODU must be
configured to HUB mode. A change is effective
immediately.
RO Available states of the TDM Transmit Clock
Control each input status is represented by a
bit. When the state is available the bit value is
1. When the state is unavailable the bit value
is 0. The available states are: bit 2 =
Transparent bit 3 = Local Loop Timed bit 4 =
Remote Loop Timed bit 5 = Local Internal bit 6
= Remote Internal
RW Required state of the TDM Transmit Clock
Control. A change is effective after re‐activation
of the TDM service.
RO Actual state of the TDM Transmit Clock Control.
Chapter C
C‐27
